Wire Bobbin cart - 1330 x 980 mm

Custom designed hanging cart used for carrying smaller materials that need to be hung.

100% free. No commitment.

Automotive 353 lbs
load capacity

Wire Bobbin cart – 1330 x 980 mm

First Name Last Name Email Company City Country Phone Quantity

Comments (optional) Attach a file (optional) Upload

Maximum file size is 10mb.

We will get back to you within 24 hours. (Unless it’s during holidays.)

Technical specifications

Category	Hanging Carts, Standard
Industry	Defense Equipment, Industrial Machinery, Wind & Energy
Width	39 inch
Length	52 inch
Levels	6
Load capacity	353 lbs
Load Capacity per Level	88 lbs
Transportation method	Manual
Caster size	8 inch
Caster Type	Polyurethane
Type of Load	Misc parts

More info

This cart is designed to hang components and easily transport materials. It is assembled with a floor brake and a handlebar attachment for ease of use. A Tow bar can also be attached to this industrial cart.

Parts included

FlexBeam™ 910 mm 6 Q-001-1304

FlexBeam™ 700 mm 4 Q-001-1307

FlexBeam™ 1190 mm FE 1 Q-001-1400

FlexBeam™ 420 mm FE 12 Q-001-1411

FlexBeam™ - 1330 mm FE 3 Q-001-1501

FlexPlate™ 16 Q-002-1001

Stiffener - Outside 6 Q-002-1050

Flexplate™ M10 2 Q-002-1162

Wheel Attachment - 105 x 77,5 mm 4 Q-004-1065

Caster Polyurethane - 200 mm 2 Q-004-1100

Caster Polyurethane 200 mm Fixed 2 Q-004-1101

Floor Brake LTL - 200 mm 1 Q-004-1359

Cross Joint - 240 x 240 mm 6 Q-005-0021

L Bracket Joint 2 Q-005-0031

Spring Threaded Tube Connectors 4 Q-005-0469

Wheel Attachment Box 4 Q-005-1079

64 mm FlexBeam™ Collet 18 Q-005-1426

Heavy Duty Joint M10 2 Q-005-1580

Hex Head - M10 x 25 mm 42 Q-006-1041

Locking Nut M10 85 Q-006-1042

Hex Head - M10 x 95 mm 8 Q-006-1088

Hex Head - M10 x 90 mm 6 Q-006-1132

Extra Low Head - M10 x 90 mm 23 Q-006-1381

Self Tapping Screw M6 Torx H60 x 16 128 Q-006-1384

Extra Low Head Allen - M10 x 25 mm 10 Q-006-1410

Handlebar Attachment EUR 1 Q-015-0026

Handlebar / Floor brake attachment EUR 1 Q-015-0027

Tube for Handlebar EUR 1 Q-015-0033
