Q-100-1254

Pallet Trolley - 1680 x 1260 mm

Basic pallet/container cart, can be transported by frame or manually. Equipped with four nylon casters, two fixed and two swivel with brake.

100% free. No commitment.

Automotive 1653 lbs
load capacity

Pallet Trolley – 1680 x 1260 mm

First Name Last Name Email Company City Country Phone Quantity

Comments (optional) Attach a file (optional) Upload

Maximum file size is 10mb.

We will get back to you within 24 hours. (Unless it’s during holidays.)

Technical specifications

Category	Standard
Industry	Automotive, Defense Equipment, Distribution, Industrial Machinery, Tier One Suppliers, Wind & Energy
Width	50 inch
Length	66 inch
Load capacity	1653 lbs
Transportation method	LiftRunner Frames, Manual
Caster size	8 inch
Caster Type	Nylon

More info

Basic pallet/container cart, since it doesn’t have a flatbed it can only be used for one container size. The cart can be transported by frame or manually if you have a high container to push. The cart is equipped with four nylon casters, two fixed and two swivel with brake making it easy to maneuver manually.

Parts included

FlexBeam™ - 1610 mm 4 Q-001-1294

FlexBeam™ 1190 mm FE 2 Q-001-1400

FlexBeam™ 1050 mm FE 2 Q-001-1402

Flexplate M10 Countersunk 4 Q-002-0009

FlexPlate™ 12 Q-002-1001

Polyamide Caster 200 mm with Brake 2 Q-004-1351

Polyamide Caster 200 mm Fixed 2 Q-004-1354

Pallet Guide Wheel Attachment Right 2 Q-005-0062

Pallet Guide Wheel Attachment Left 2 Q-005-0063

Locking Nut M10 16 Q-006-1042

Extra Low Head - M10 x 90 mm 16 Q-006-1381

Self Tapping Screw M6 Torx H60 x 16 48 Q-006-1384

Countersunk Self Tapping Screw - M6 x 20 48 Q-006-1385
