Q-100-1014

Pallet Cart - 1680 x 1260 mm

Pallet cart used for a specific pallet or container size. Equipped with a floor brake and four polyurethane casters and angled pallet guides.

100% free. No commitment.

Automotive 1102 lbs
load capacity

Pallet Cart – 1680 x 1260 mm

First Name Last Name Email Company City Country Phone Quantity

Comments (optional) Attach a file (optional) Upload

Maximum file size is 10mb.

We will get back to you within 24 hours. (Unless it’s during holidays.)

Technical specifications

Category	Standard
Industry	Automotive, Defense Equipment, Distribution, Industrial Machinery, Tier One Suppliers, Wind & Energy
Width	50 inch
Length	66 inch
Load capacity	1102 lbs
Transportation method	LiftRunner Frames, Manual
Caster size	5 inch
Caster Type	Polyurethane

More info

This frame is used for the transportation of pallets or containers. Since it doesn’t have a flat deck it only works for a certain container size. The cart is equipped with a floor brake and four polyurethane swivel casters, two with brake making it easy to maneuver in tight areas as well as angled pallet guides to ease the loading process.

Parts included

FlexBeam™ - 1610 mm 4 Q-001-1294

FlexBeam™ 1120 mm FE 4 Q-001-1401

FlexBeam™ 1260 mm FE 2 Q-001-1500

FlexPlate™ 10 Q-002-1001

Flexplate™ M10 12 Q-002-1162

Caster Polyurethane - 125 mm 4 Q-004-1106

Floor Brake LTL - 125 mm 2 Q-004-1360

Floor brake plate 2 Q-005-0275

Wheel Attachment Box 4 Q-005-1079

Angled Corner Plate 4 Q-005-1098

64 mm FlexBeam™ Collet 16 Q-005-1426

Hex Head - M10 x 25 mm 18 Q-006-1041

Locking Nut M10 60 Q-006-1042

Washer M10 32 Q-006-1043

Hex Head - M10 x 95 mm 2 Q-006-1088

Hex Head - M10 x 90 mm 8 Q-006-1132

Extra Low Head - M10 x 90 mm 14 Q-006-1381

Self Tapping Screw M6 Torx H60 x 16 40 Q-006-1384

Extra Low Head Allen - M10 x 25 mm 18 Q-006-1410
