Low Tugger Cart - 1050 x 1400 mm

This low rider pallet cart is designed to transport pallets, boxes or containers.

100% free. No commitment.

Automotive 265 lbs
load capacity

Low Tugger Cart – 1050 x 1400 mm

First Name Last Name Email Company City Country Phone Quantity

Comments (optional) Attach a file (optional) Upload

Maximum file size is 10mb.

We will get back to you within 24 hours. (Unless it’s during holidays.)

Technical specifications

Category	Flat Deck
Industry	Automotive, Defense Equipment, Distribution, Industrial Machinery, Tier One Suppliers, Wind & Energy
Width	41 inch
Length	55 inch
Load capacity	265 lbs
Transportation method	Manual, Tugger
Caster size	5 inch
Caster Type	Polyurethane

More info

This low rider cart can be used to transport pallets, containers, boxes or loose components. It is designed to have the platform at a low height from the floor to be able to use a specific type of lifting device. This cart is equipped with polyurethane casters and a foot release tow bar.

Parts included

FlexBeam™ 1050 mm FE 8 Q-001-1402

FlexBeam™ 1260 mm FE 2 Q-001-1500

Caster Polyurathane 125 mm 80 x 60 Swivel 2 Q-004-1220

Caster Polyure. 125 mm 80 x 60 Fixed 2 Q-004-1221

Triangle Joint 4 Q-005-0483

Extended caster attachment - 180 x 160 (Welded) 4 Q-005-0881

Collet 32 x 15 x M10 Threads 12 Q-005-0924

Collet - 31 mm 2 Q-005-1008

Spring Cover Plate 1 Q-005-1025

64 mm FlexBeam™ Collet 12 Q-005-1426

Hat Profile - 1260 x 38 mm 3 Q-005-2331

Hex Head Fully Threaded - M8 x 20 mm 16 Q-006-1019

Hex Head - M14 x 60 mm 2 Q-006-1036

Locking Nut M14 2 Q-006-1039

Hex Head - M10 x 25 mm 8 Q-006-1041

Locking Nut M10 77 Q-006-1042

Hex Head - M10 x 95 mm 3 Q-006-1088

Countersunk - M10 x 70 mm 1 Q-006-1112

Hex Head - M10 x 90 mm 23 Q-006-1132

Locking Nut M8 16 Q-006-1181

Hex Head Fully Threaded - M10 x 50 mm 2 Q-006-1343

Self Tapping Screw M6 Torx H60 x 16 60 Q-006-1384

Low Allen Head - M10 x 16 mm 20 Q-006-1409

Extra Low Head Allen - M10 x 25 mm 44 Q-006-1410

Spring 1,5 x 15yd x 70 1 Q-012-1141

Top Plate w. edge - 1050 x 1260 mm 1 Q-016-0690

Countersunk Towing Lock Pin - 25 mm 1 Q-017-0010

Foot Release Locking Lip 1 Q-017-0024

Heavy Duty Tow Hinge - Narrow 1 Q-017-0087

Tow Hole 28 mm - Symmetric 1 Q-017-1066
