Q-100-1467

Low Rider Tugger Cart - 1120 x 1190 mm

Low rider pallet cart which is designed to transport pallets and containers.

100% free. No commitment.

Automotive 882 lbs
load capacity

Low Rider Tugger Cart – 1120 x 1190 mm

First Name Last Name Email Company City Country Phone Quantity

Comments (optional) Attach a file (optional) Upload

Maximum file size is 10mb.

We will get back to you within 24 hours. (Unless it’s during holidays.)

Technical specifications

Category	Flat Deck
Industry	Automotive, Defense Equipment, Distribution, Industrial Machinery, Tier One Suppliers, Wind & Energy
Width	44 inch
Length	47 inch
Load capacity	882 lbs
Type of tow bar	Tongue and Hitch
Transportation method	Manual, Tugger
Caster size	5 inch
Caster Type	Polyurethane
Type of Load	Pallets and Containers

More info

This low rider pallet cart is designed to transport pallets and containers. It comes equipped with a drop pin and hitch tow bar to connect the carts in a tugger train system. This cart also utilizes corner pallet guides to locate the pallets in the platform easily. The low rider feature helps to load the pallets with special lifting devices.

Parts included

FlexPlate™ 14 Q-002-1001

Flexplate™ M10 2 Q-002-1162

Floor lock COLSON - 4 x 4-1/2 - 125 - 150 mm 1 Q-004-0031

Caster Polyurathane 125 mm 80 x 60 Swivel 4 Q-004-1220

Caster Polyure. 125 mm 80 x 60 Fixed 2 Q-004-1221

L Bracket Joint 4 Q-005-0031

Pallet Guide Corner Plate 4 Q-005-1096

64 mm FlexBeam™ Collet 24 Q-005-1426

Wheel Attachment - 80 x 60 mm 2 Q-005-1722

Hex Head - M14 x 60 mm 4 Q-006-1036

Locking Nut M14 4 Q-006-1039

Hex Head - M10 x 25 mm 9 Q-006-1041

Locking Nut M10 48 Q-006-1042

Washer M10 32 Q-006-1043

Hex Head - M10 x 95 mm 5 Q-006-1088

Hex Head - M10 x 90 mm 12 Q-006-1132

Hex Head - M10 x 30 mm 4 Q-006-1161

Locking Nut M8 24 Q-006-1181

Countersunk - M8 x 20 24 Q-006-1282

Extra Low Head - M10 x 90 mm 13 Q-006-1381

Self Tapping Screw M6 Torx H60 x 16 56 Q-006-1384

Countersunk Self Tapping Screw - M6 x 20 40 Q-006-1385

Low Allen Head - M10 x 16 mm 2 Q-006-1409

Extra Low Head Allen - M10 x 25 mm 3 Q-006-1410

FlexHandle low rider w floor lock plate - 700 x 900 mm 1 Q-015-0090

Top Plate - 1120 x 1190 mm 1 Q-016-0792

US Modular Tow Bar VKR - Lip - 380 mm 1 Q-017-0015

Spring Loaded Tow Hinge 1 Q-017-0067

Heavy Duty Tow Hinge - Narrow 1 Q-017-0087

Towing Lip - 28 mm 1 Q-017-1010

FlexBeam™ - 1120 mm 4 Q-020-1120

FlexBeam™ STS FE - 980 mm 2 Q-021-0980

FlexBeam FE - 1050 mm 2 Q-021-1050
