Q-100-0808

Flow Shelf Cart - 1540 x 770 mm

Custom flow shelf cart for presenting materials to the operators.

100% free. No commitment.

Automotive 298 lbs
load capacity

Flow Shelf Cart – 1540 x 770 mm

First Name Last Name Email Company City Country Phone Quantity

Comments (optional) Attach a file (optional) Upload

Maximum file size is 10mb.

We will get back to you within 24 hours. (Unless it’s during holidays.)

Technical specifications

Category	Flow Shelf
Industry	Appliances & Electronics, Distribution, Medical Equipment
Width	30 inch
Length	61 inch
Levels	3
Load capacity	298 lbs
Load Capacity per Level	99 lbs
Transportation method	Manual
Caster size	5 inch
Caster Type	Gray
Type of Load	Bins, Boxes, Misc parts, Totes

More info

This flow shelf cart is equipped with three flow shelves that can hold smaller bins, totes, and boxes. The height of these shelves can be easily adjusted higher or lower depending on the height of your materials.

Parts included

FlexTube™ 630 mm 2 Q-000-1312

FlexQube 4 Q-001-1078

FlexBeam STS - 1680 mm 8 Q-001-1293

FlexBeam™ - 1470 mm 4 Q-001-1296

FlexBeam™ 770 mm FE 2 Q-001-1406

FlexPlate™ 14 Q-002-1001

125 mm Swivel Caster with Brake 4 Q-004-1364

Caster to Beam Attachment - 80 x 60 mm 4 Q-005-0265

Beam to Beam Corner Plate 4 Q-005-1356

64 mm FlexBeam™ Collet 12 Q-005-1426

Locking Nut M10 24 Q-006-1042

Locking Nut M8 16 Q-006-1181

M8 x 16 mm Countersunk 16 Q-006-1214

Extra Low Head - M10 x 90 mm 12 Q-006-1381

Self Tapping Screw M6 Torx H60 x 16 160 Q-006-1384

Extra Low Head Allen - M10 x 25 mm 12 Q-006-1410

Flow Shelf - 1400 x 1048 mm - 280 mm drop 3 Q-016-0387
