Flat Shelf Tugger cart 70 x 36 inch - 4 Shelves
Flat Shelf Tugger cart 70 x 36 inch
Flat Shelf Tugger cart 70 x 36 inch - 4 Shelves
Flat Shelf Tugger cart 70 x 36 inch - 4 Shelves
Flat Shelf Tugger cart 70 x 36 inch - 4 Shelves
Flat Shelf Tugger cart 70 x 36 inch
Q-100-0393

1 / 4

Flat Shelf Tugger cart w. handlebars 70 x 36 inch

FlexQube’s Four-level tuggable flat shelf cart equipped with a floor brake, handlebars, and six polyurethane casters.

100% free. No commitment.

Automotive 882 lbs
load capacity
Get a quote
Close

Flat Shelf Tugger cart w. handlebars 70 x 36 inch

Maximum file size is 10mb.

We will get back to you within 24 hours. (Unless it’s during holidays.)

Technical specifications
Transportation method Manual, Tugger
Type of tow bar Tongue and Hitch
Industry Defense Equipment, Industrial Machinery, Wind & Energy
Category Flat Shelf
Length 69 inch
Width 36 inch
Load capacity 882 lbs
Levels 4
Load Capacity per Level 220 lbs
Caster size 5 inch
Caster Type Polyurethane
More info

Four-level tuggable flat shelf cart most commonly used for the transportation of totes, bins, or boxes. The cart is equipped with a floor brake, handlebars and six high-quality polyurethane casters, two fixed and four swivel giving it excellent tracking properties and silent movement when connected in a train.

Parts included
FlexTube™ 770 mm 2 Q-000-1265
FlexBeam™ - 1470 mm 8 Q-001-1296
FlexBeam™ 1050 mm 4 Q-001-1302
FlexBeam™ 630 mm 4 Q-001-1308
FlexBeam™ 910 mm FE 2 Q-001-1404
FlexBeam™ 770 mm FE 2 Q-001-1406
FlexPlate™ 24 Q-002-1001
Flexplate™ M10 8 Q-002-1162
Wheel Attachment - 105 x 77,5 mm 8 Q-004-1065
Caster Polyurethane - 125 mm 4 Q-004-1106
Caster Polyurethane 125 mm Fixed 2 Q-004-1107
Floor Lock COLSON 4 x 4-1/2 1 Q-004-1369
Towing Hole 2 Q-005-1056
Spring for Tow Bar 2 Q-005-1070
RTE Plug 4 Q-005-1289
Beam to Beam Corner Plate 4 Q-005-1356
64 mm FlexBeam™ Collet 16 Q-005-1426
Allen Head - M6 x 30 mm 1 Q-006-1012
Hex Head - M20 x 500 mm 1 Q-006-1016
Hex Head - M14 x 60 mm 4 Q-006-1036
Fully Threaded - M10 x 120 mm 4 Q-006-1037
Locking Nut M14 4 Q-006-1039
Hex Head - M10 x 25 mm 1 Q-006-1041
Locking Nut M10 77 Q-006-1042
Washer M10 24 Q-006-1043
Locking Nut M6 1 Q-006-1050
Hex Head - M10 x 95 mm 8 Q-006-1088
Hex Head - M8 x 16 mm 88 Q-006-1120
Hex Head - M10 x 90 mm 44 Q-006-1132
Hex Head - M10 x 30 mm 2 Q-006-1161
Locking Nut M8 80 Q-006-1181
M8 Washer 40 Q-006-1183
Nut M10 1 Q-006-1195
Hex Head Fully Threaded - M10 x 50 mm 5 Q-006-1343
Extra Low Head - M10 x 90 mm 14 Q-006-1381
Self Tapping Screw M6 Torx H60 x 16 200 Q-006-1384
M20 Locking Nut 1 Q-006-1405
Extra Low Head Allen - M10 x 25 mm 3 Q-006-1410
Compression Spring for US Tow Hitch 1 Q-012-0007
Handlebar / Floor Brake Attachment US 1 Q-015-0029
Handle Bar 210 mm M8 4 Q-015-1037
Angled plate - 1738 mm 8 Q-016-0193
Flat Shelf - 805 x 910 mm 8 Q-016-0194
US Modular Tow Bar VKR - LIP - 520 mm 1 Q-017-0014
Handle for Tow Hole 1 Q-017-0022
Towing Lip - 28 mm 1 Q-017-1010
Tow Attachment to Beam 1 Q-017-1080
Tow Hinge 1 Q-017-1083
