Q-100-0627

Flat Shelf Cart - 840 x 630 mm

Custom designed flat shelf cart with three flat shelves for lighter materials.

100% free. No commitment.

Automotive 265 lbs
load capacity

Flat Shelf Cart – 840 x 630 mm

First Name Last Name Email Company City Country Phone Quantity

Comments (optional) Attach a file (optional) Upload

Maximum file size is 10mb.

We will get back to you within 24 hours. (Unless it’s during holidays.)

Technical specifications

Category	Flat Shelf
Industry	Automotive, Defense Equipment, Distribution, Industrial Machinery, Tier One Suppliers, Wind & Energy
Width	25 inch
Length	33 inch
Levels	3
Load capacity	265 lbs
Load Capacity per Level	88 lbs
Transportation method	Manual
Caster size	5 inch
Caster Type	Gray
Type of Load	Bins, Boxes, Totes

More info

This custom designed shelf cart was designed for transporting totes, bins, and boxes. It has three flat shelves, with handles attached to the top shelf. It also comes with four high quality swivel casters for easier movability.

Parts included

FlexBeam™ 770 mm 4 Q-001-1306

FlexBeam™ 910 mm FE 2 Q-001-1404

FlexBeam™ 630 mm FE 2 Q-001-1408

FlexPlate™ 4 Q-002-1001

125 mm Swivel Caster with Brake 4 Q-004-1364

Caster to Beam Attachment - 80 x 60 mm 4 Q-005-0265

Beam to Beam Corner Plate 2 Q-005-1356

64 mm FlexBeam™ Collet 8 Q-005-1426

Locking Nut M10 26 Q-006-1042

Washer M10 8 Q-006-1043

M8 x 20 mm MELC6S 10.9 Allen Head 4 Q-006-1044

Locking Nut M8 20 Q-006-1181

M8 x 16 mm Countersunk 16 Q-006-1214

Extra Low Head - M10 x 90 mm 8 Q-006-1381

Self Tapping Screw M6 Torx H60 x 16 34 Q-006-1384

Extra Low Head Allen - M10 x 25 mm 18 Q-006-1410

M8 Handle - 140 mm 2 Q-015-1409

Flat Shelf - 852 x 630 mm (w. fixed mounting) 3 Q-016-0285
